SP 15C SUBWOOFER 15"/38CM 500W RMS (UNIT PRICE)
Pay in easy, interest-free installments with Klarna.
SUPER POWER AUDIODESIGNED IN ITALY
MMXXVI
500 watt RMS.
65.5 mm voice coil.
A 15" / 38 cm subwoofer built around a 65.5 mm (2.5") dual voice coil: 4 ohm rated, 2+2 ohm coils, 500 W RMS continuous, 1000 W peak, 89 dB sensitivity. Compressed paper and fibreglass cone, large “R” suspension, 180 °C aluminium winding. Sold per unit. Manufacturer's recommended vented box: 100 L tuned to 30 Hz.
Power, measured not promised
RMS = CONTINUOUS POWER. THE PEAK FIGURE IS A SHORT-TERM VALUE: SIZE THE AMPLIFIER ON THE 500 W RMS
Why this subwoofer
Not a burst figure: 500 W RMS is the power the voice coil handles continuously, with 1000 W of peak headroom on top.
The bigger the coil, the more heat it dissipates and the longer it survives a real session. Wound with 180 °C aluminium wire.
Two coils: in parallel 1 ohm, in series 4 ohm. You choose the impedance that matches your amplifier instead of the other way round.
A 85 oz Y30 ferrite magnet under a compressed paper and fibreglass cone with a large “R” suspension: 12 mm Xmax of usable excursion.
Look at it closely
Voice coil wiring, impedance, mounting and full specifications.
⇩ Open the manual (PDF)PDF · Google Drive
What you receive
One SP 15C subwoofer, sold as a single unit, in its SP Audio box.
Not included: enclosure, amplifier, cables and fixings.
Technical specifications
| SUBWOOFER — SPECIFICATIONS | |
|---|---|
| Nominal diameter | 380 mm (15") |
| Rated impedance | 4 ohm |
| Minimum impedance | 2+2 ohm, dual voice coil |
| Rated power (RMS) | 500 W |
| Peak power (MAX) | 1000 W |
| Sensitivity | 89 dB SPL 1W/1M |
| Frequency range | 25–300 Hz |
| Voice coil diameter | 65.5 mm / 2.5" |
| Winding material | 180 °C aluminium wire |
| Magnet | 85 oz Y30 ferrite |
| Suspension | Large “R” form |
| Cone | Compressed paper + fibreglass + black painting |
| Sold as | Single unit |
| THIELE-SMALL PARAMETERS | |
|---|---|
| Fs | 28.54 Hz |
| Qts | 0.498 |
| Qms | 5.025 |
| Qes | 0.553 |
| Vas | 117.79 L |
| Re | 2+2 ohm |
| Mms | 242.198 g |
| Cms | 128.37 µm/N |
| Xmax | 12 mm |
| Sd | 804.2 cm² |
| Dd | 32.00 cm |
| Bl | 17.73 T·m |
| SPL | 89 dB |
| RECOMMENDED VENTED BOX | |
|---|---|
| Volume | 100 L |
| Tuning frequency | 30 Hz |
| Vent shape | Circle |
| Vent diameter | ø102 mm |
| Vent length | 17.23 cm |
| Cross-sectional area | 81.7 cm² |
| End correction | Two flanged ends |
MANUFACTURER'S LABORATORY DATA · PEAK OR “BURST” FIGURES USED IN SOME MARKETS ARE NOT RMS
Complete the system
Before you install it
- Decide the impedance before you wire it. The two 2 ohm coils in parallel give 1 ohm; in series they give 4 ohm. Check that your amplifier is stable at the impedance you choose.
- Match the amplifier to 500 W RMS. Sizing on the 1000 W peak figure means overdriving the coil: use the RMS value.
- Build the enclosure rigid. The manufacturer gives a vented box of 100 L tuned to 30 Hz: thick panels, braced and sealed, or the box will lose output and rattle.
- Size the power cable for the amplifier with an inline fuse close to the battery and a ground point on bare metal.
